Incoming Calls
Cisco700 Series Router Configuration Guide
2-6
In the following example, the profile parameter number is removed from the profile by
using the unset command:
Host:Profile> unset number
Deleting Profiles
The reset user command deletes a user-defined profile from the router. The three
permanent profiles (LAN, Internal, and Standard) cannot be deleted. This command also
closes any connection associated with the profile.
In the following example, the tomd profile is removed from the system by using the
reset user command:
Host:Profile> reset user tomd
Changing Profile Names
The set profile user command changes the name ofan existing profile. Enter this command
while in profile mode for the profile you want to affect. In the following example, the profile
name is being changed from 2500 to 4500:
766:2500> set profile user 4500
766:4500>
Incoming Calls
When the router receives an incoming call, the router searches both active and inactive
profiles for a profile with the same name as the calling device. If it finds a profile with the
matching user ID, the router uses the configuration parameters of that profile while
communicating with the remote device. If the profile is inactive, it is automatically
activated for the duration of the connection.
When the call is finished, the physical link between the two devices is disconnected.
However, the virtual connection to the remote router might be configured to remain active.
