2-11
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-04
Chapter 2 Route Switch Processors and Supervisor Engines
RSP720 with 10GE Uplink Ports
• In 10GE only mode, eight queues are available for QoS. Use the mls qos supervisor 10g-only
command to enable 10GE only mode.
The QoS port architecture for 10GE only mode is as follows (Rx/Tx):
–
8q8t/1p7q8t (CoS)
–
16q8t/1p15q8t (DSCP)
–
16q1t/1p15q1t (VLAN)
QoS Configuration Guidelines
As you configure QoS on the RSP720-10GE, consider the following:
• When you switch between mixed-mode QoS and 10GE only mode, any existing QoS configuration
on the uplinks is lost. You must reconfigure QoS.
• While transitioning between modes, service will be temporarily lost on the uplinks.
• You can manually shut down all three 1GE ports before issuing the mls qos supervisor 10g-only
command to switch to 10GE only mode. If you do not shut down the ports first, the mls qos
supervisor 10g-only command shuts down the ports.
• When you switch from 10GE10GE only to mixed-mode QoS, you must issue the no shutdown
command on each of the three 1GE ports to resume QoS service on those ports.
• In 10GE only mode, the 1GE ports are visible but they remain in an administratively down state.
Configuring 10GE Only QoS
Cisco IOS Release 12.2SRC introduces a new command to enable QoS features on 10GE uplink ports
only. By default, the router runs in mixed mode, which means that QoS is enabled on both the 10GE
uplink ports and the 1GE uplink ports.
mls qos supervisor 10g-only
no mls qos supervisor 10g-only
Note You can shut down all three 1GE uplink ports before entering the mls qos supervisor 10g-only
command. If you do not shut down the ports first, the mls qos supervisor 10g-only command shuts down
the ports.
