Figure 8: AC/DC Power Input Terminal Block
1. Ground Wire
Step 2 Insert the exposed ground wire lead into the power converter ground wire connection. Ensure that only wire with insulation
extends from the connector.
Figure 9: Connecting AC Power to the Power Converter
Ground1
AC neutral2
Cisco 809 Industrial Integrated Services Router Hardware Installation Guide
39
Connecting the Router
Connecting the Power Converter to an AC Power Source
