Cisco 870 Series User Manual

3-3
Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 3 Router and PoE Module Mounting Procedures
Mounting on a Wall
Figure 3-1 Mounting Brackets on the Bottom of the Router
Figure 3-2 shows the locations of the mounting screws and the router mounting brackets, and the
placement of the power adapter.
1 Distance between two top mounting brackets
(near the front panel)
3 Vertical distance between the top mounting
brackets and the bottom bracket
2 Midpoint between the two top mounting
brackets (near the front panel)
127042
1
2
3
