12 Checking the Access Point LEDs
Note Regarding LED status colors, it is expected that there will be small variations in color intensity
and hue from unit to unit. This is within the normal range of the LED manufacturer’s
specifications and is not a defect.
The access point status LED indicates various conditions and are described in Table 2.
Table 2 LED Status Indications
Message Type LED State Message Meaning
Association status Green Normal operating condition, but no
wireless client associated
Blue Normal operating condition, at least
one wireless client association
Boot loader status Green Executing boot loader
Boot loader error Blinking Green Boot loader signing verification
failure
Operating status Blinking Blue Software upgrade in progress
Alternating between Green and Red Discovery/join process in progress
Cycling through
Red-Off-Green-Off-Blue-Off
Access point location command
invoked from controller web
interface.
Access point operating
system errors
Cycling through
Blue-Red-Green-Off
General warning; insufficient inline
power
