Figure 40: Replacing Supercap

Hinged latch2Securing tab1

Replacing a SATA Interposer Card

For software-based storage control that uses the server's embedded SATA controller, the server requires a

SATA interposer card that plugs into a horizontal socket on a dedicated mRAID riser (internal riser 3).

You cannot use a hardware RAID controller card and the embedded software RAID controller at the same

time.

Note

Step 1 Prepare the server for component installation:

Cisco APIC M3/L3 Server Installation and Service Guide

Maintaining the Server

Replacing a SATA Interposer Card

Questions and Answers:

Need help?

Do you have a question about the Cisco APIC M3 and is the answer not in the manual?

General

Product Type	Application Policy Infrastructure Controller
Model	APIC-M3
Form Factor	Rack-mountable
CPU Clock Speed	2.2 GHz
Power Supply	Dual redundant
Processor	Intel Xeon
Memory	64 GB
Management Port	1 x 1 Gigabit Ethernet
Power Supply Capacity	770W
Management	Cisco APIC
Operating System	Cisco APIC Software
Weight	35 lb (15.9 kg)
