Cisco AS5400 - Page 16

16
Step 1 Connect the terminal to the console port using an RJ-45 rollover cable and an RJ-45-to-DB-25 or RJ-45-to-DB-9
adapter. The adapters provided are labeled TERMINAL. The adapters and the rollover cable are included in the
accessory kit that ships with the universal gateway.
Connecting Cisco AS5350 to Console Terminal
Connecting Cisco AS5400 to Console Terminal
35676
RJ-45-to-RJ-45
rollover cable
PC (laptop)
RJ-45
Console port
(RJ-45)
30845
Console port
(RJ-45)
RJ-45-to-RJ-45
rollover cable
PC (laptop)
RJ-45
