Console ports
Two serial ports, a mini USB Type B, and a
standard RJ-45 (8P8C), are provided for
management access via an external system. See
Console Ports, on page 6 for additional
information.
6Management port
A Gigabit Ethernet interface
restricted to network
management access only.
Connect with an RJ-45 cable.
5
Reset button
A small recessed button that if pressed for longer
than three seconds resets the ASA to its default
“as-shipped” state following the next reboot.
Configuration variables are reset to factory default.
However, the flash is not erased, and no files are
removed.
You can use the service sw-reset-button
to disable the reset button. The default is
enabled.
Note
8USB port
A standard USB Type A port
is provided, allowing
attachment of an external
device such as mass storage.
See Internal and External
Flash Storage, on page 6 for
additional information.
7
SSD bay
Covered slot in which the SSD is installed. You
can replace this drive if it fails. See Replace the
SSD , on page 27 for more information.
10SSD LED
Status light for installed
solid-state drive (SSD). See
LEDs, on page 4 and Solid
State Drive, on page 7 for
more information.
9
LEDs
The LEDs are located just off center on the front panel, and just to the left of the network ports on the rear
panel, with the SSD LED to the right of the Reset port.
DescriptionLED
Power supply status:
• Unlit – Power supply off.
• Solid green – Power supply on.
See Power Supply Modules, on page 7 for additional power information.
Power
Cisco ASA 5508-X and ASA 5516-X Hardware Installation Guide
4 Online Only
Overview
LEDs
