Figure
49:
Installing
the
Cisco
ASR
9904
Router
Chassis
in
a
Standard
2-Post
Rack
Six
screws
per
side
(minimum)
to
attach
the
router
chassis
to
the
rack.
1
The
figure
below
shows
the
orientation
of
the
Cisco
ASR
9906
Router
chassis
to
the
rack
posts
and
components
used
in
the
installation.
Unpacking
and
Installing
the
Chassis
53
Unpacking
and
Installing
the
Chassis
Installing
the
Chassis
in
a
2-Post
Rack
52
54
