Cisco ASR-920-24TZ-M - USB Flash or MEM Port Pinouts; RJ45 C Port Pinouts

USB Flash or MEM Port Pinouts
The table below summarizes the USB flash or MEM port pinouts.
Table 23: Single USB Flash or MEM Port Pinouts
DescriptionSignal NamePin
+5VDC (500mA)VccA1
Data -D-A2
Data +D+A3
GroundGndA4
USB TYPE-A receptacle is used.Note
The USB flash or MEM port +5VDC is output. Cisco ASR 920-24SZ-IM, ASR-920-24SZ-M,
ASR-920-24TZ-M Router provides power for USB flash or MEM port. This port operates as a USB host
device.
Note
RJ45C Port Pinouts
The table below summarizes the RJ45C port pinouts on the 8 Port T1/E1 Interface Module.
Table 24: RJ45C Port Pinouts
Signal NamePin
RX_TIP1
RX_RING2
TX_TIP4
TX_RING5
Not Connected3, 6, 7, 8
