Cisco ATA 186 Configuration Guide

CafeFone Configuration Guide for the Cisco ATA186
The shaded values denote required fields.
CISCO ATA 186 WEB CONFIGURATION
UIPassword ToConfig
0
UseTftp
0
TftpURL
0
CfgInterval
3600
EncryptKey
0
Dhcp
1
StaticIP
10.1.1.108
StaticRoute
10.1.1.1
StaticNetMask
255.255.255.0
UID0
NOPHONE
PWD0
Passcode for CafeFone account
number for line 1.
UID1
NOPHONE1
PWD1
Passcode for CafeFone account
number for line 2. If only using line 1,
leave blank (0).
GkOrProxy
sip.cafefone.com
Gateway
0
GateWay2
0.0.0.0
UseLoginID
1
LoginID0
CafeFone account number.
LoginID1
CafeFone account number.
If only using Port 1, leave blank (0).
AltGk
0
AltGkTimeOut
0
GkTimeToLive
300
GkId
.
UseSIP
1
SIPRegInterval
300
MaxRedirect
5
SIPRegOn
1
NATIP
0.0.0.0
SIPPort
5060
MediaPort
10000
OutBoundProxy
0
NatServer
0
NatTimer
0x00000000
LBRCodec
0
AudioMode
0x00150015
RxCodec
0
TxCodec
0
NumTxFrames
1
CallFeatures
0xffffffff
PaidFeatures
0x00000000
CallerIdMethod
0x00019e60
CallWaitCallerId
0x003c33d0
Polarity
0x00000000
ConnectMode
0x00060400
AutMethod
0x00000002
TimeZone
17
NTPIP
0.0.0.0
AltNTPIP
0.0.0.0
DNS1IP
0.0.0.0
DNS2IP
0.0.0.0
UDPTOS
0x000000a0
SigTimer:
0x01418564
OpFlags
0x00000002
Nprintf
0.0.0.0.0
TraceFlags
0x00000000
RingOnOffTime
2,4,25
IPDialPlan
1
DialPlan
#.r9t1|**St4-|#St4-|911|1>#t8.r9t2-
|0>#t811.rat4-|^1t4>#.-
DialTone
2,31538,30831,3100,3885,1,0,0,1000
BusyTone
2,30467,28959,1191,1513,0,4000,4000,
0
ReorderTone
2,30467,28959,1191,1513,0,2000,2000
,0
RingBackTone
2,30831,30467,1943,2111,0,16000,320
00,0
CallWaitTone
1,30831,0,5493,0,0,2400,2400,4800
AlertTone
1,30467,0,5970,0,0,480,480,1920
CallCmd
Af;AH;BS;NA;CS;NA;Df;EB;Ff;EP;
Kf;EFh;HQ;Jf;AFh;HQ;I*67;gA*82;f
A#90v#;OI;H#72v#;bA#74v#;cA#7
5v#;dA#73;eA*67;gA*82;fA*70;iA*6
9;DA*99;xA;Uh;GQ;
Page 5

Cisco ATA 186 Specifications

General

Operating Temperature	32°F to 104°F (0°C to 40°C)
Protocol	SIP, H.323
Network Interface	10/100BASE-T Ethernet
Audio Codec Support	G.729a, G.723.1
Power Supply	5V DC
Weight	0.23 kg (0.5 lb)
Relative Humidity	10 to 90% noncondensing
Ports	2 RJ-11 FXS ports
