Usage GuidelinesDescriptionField Name
Allows you to select from one of 8
different ringtones for call back
notifications
-
Default setting: 7
Call Back Ring
Enter the length of the ring when a
call is forwarded, from 0 – 10
seconds.
-
Default setting: 0
Cfwd Ring Splash Len
Enter the length of the ring for the
call back notifications, from 0 – 10
seconds.
-
Default setting: 0
Cblk Ring Splash Len
Enter the length of the ring for your
voicemail notifications, from 0 – 10
seconds.
-
Default setting: 0
VMWI Ring Splash Len:
Log
The ATA allows you to record incoming, outgoing, and DHCP lists for various events that occur on your
network. The Incoming Log displays a temporary list of the source IP addresses and destination port numbers
for the incoming Internet traffic. The Outgoing Log displays a temporary list of the local IP addresses,
destination URLs/IP addresses, and service/port numbers for the outgoing Internet traffic.
Debug Log Module
Use the Administration > Log > Debug Log Module page to enable and configure logging.
• As a best practice, we recommend that you enable logging only when needed, and disable logging when
you finish the investigation. Logging consumes resources and can impact system performance.
• In this page, you can select the modules which you want to see debug messages in all severity levels.
Debug Log Setting
If Debug Log Server is enabled on the Administration > Log > Debug Log Server page, the ATA will send
the debug messages to one server.
Enter the settings as described below. After making changes, click Submit to save your settings, or click
Cancel to redisplay the page with the saved settings.
Table 10: Debug Log Setting
DescriptionField
Enter the maximum size of the log file in kilobytes. Valid values are
from 128 to 1024.
Debug Log Size
Cisco ATA 191 and ATA 192 Analog Telephone Adapter User Guide for Multiplatform Firmware
19
Configure Features
Log
