Figure 56: LTE Pluggable - C1118-8PLTEAP
DescriptionItem
Mini-PCIE1
Common heat spreader + thermal interface2
I/O3
Enclosure base to support 4-antenna4
4-1 SMA-MHF4 cable assembly5
SMA Diversity Antenna for usability and Micro-USB port access6
Figure 57: LTE Pluggable - C1118-8PLTEAP Back Panel
