Figure 39: Wall mount using key-hole slots - C1101-4P

Key-hole slots

Key-hole slots-spacing: 3.024 in (76.81 mm)

Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router

Install and Connect the Router

Wall Mount Using Key-hole Slots
