Figure 47: Chassis Ground Connection-Cisco 111x

Screw (UNC 6-32)1

Ground Lug2

Figure 48: Chassis Ground Connection-Cisco 1101-4PLTEP

Screw (UNC 6-32)1

Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router

Install and Connect the Router

Chassis Grounding
