Cisco C1111x-8P

Figure 54: LTE Pluggable Interface Module - C1101-4P
GPS antenna (SMA)1
LTE antenna (SMA)2
Ground lug3
Kensingston lock slot4
Figure 55: LTE Pluggable Interface Module - C1127X-8PLTEP
GPS antenna (SMA)1
LTE antenna (SMA)2
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
63
Install and Upgrade Internal Modules and Field Replaceable Units
Install a Pluggable Interface Module on a C1101-4P
