Cisco C1111x-8P

R314
Figure 57: 5G Pluggable Interface Module - P-5GS6-GL
PID1
antenna 1 (SMA)2
GPS (SMA)3
Antenna 3 (SMA, reception only)4
Antenna 0 (SMA)5
Antenna 2 (SMA)6
Enable LED7
SIM 0 LED8
SIM 1 LED9
GPS LED10
M3.5 thumb-screw11
Service LED12
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
65
Install and Upgrade Internal Modules and Field Replaceable Units
Install a Pluggable Interface Module on a C1101-4P
