Figure 27: 125W AC Power Supply
AC OK LED3Release latch1
PS OK LED4AC power cord connector2
If no power supply is installed in a power supply slot, install a power supply slot cover.
Figure 28: Power Supply Slot Cover
Retainer clips2Release handles1
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
43
Installing a Power Supply Unit
Power Supply Modules Overview
