Step 4 Ensure that the release latch on the switch module is in the open position (perpendicular to
the module):
Step 5 Slide the switch module into the bay until it stops. (See Figure 4.)
Figure 4 Installing the Switch Module into the Blade Server Interconnect Module Bay
1
Switch module release latch
