Verifying Interface Settings and Port Operation
Follow these steps to verify that your interface configurations have been set properly and that the
controller ports are operational.
Step 1
Enter show interface summary, and press Enter. This display shows the controller interface
configurations:
Interface Name Port Vlan Id IP Address Type Ap Mgr
------------------------------ ---- -------- -------------- ------- -----
ap-manager LAG 10 10.91.104.99 Static Yes
management LAG 10 10.91.104.93 Static No
service-port N/A N/A 10.10.0.9 Static No
virtual N/A N/A 1.1.1.1 Static No
Link aggregation (LAG) is always enabled for the integrated wireless LAN controller and
cannot be disabled. LAG bundles all of the controller distribution system ports into a
single IEEE 802.3ad port channel. See the Cisco Wireless LAN Controller Configuration
Guide 4.0 or later for more information.
Step 2
Enter show port summary, and press Enter. This display shows the status of the controller
distribution system ports, which serve as the data path between the controller and the
Cisco lightweight access points and to which the controller management and AP-manager
interfaces are mapped.
STP Admin Physical Physical Link Link Mcast
Pr Type Stat Mode Mode Status Status Trap Appliance POE
-- ------- ---- ------- ---------- ---------- ------ ------- --------- -------
1 Normal Forw Enable Auto 1000 Full Up Enable Enable N/A
2 Normal Forw Enable Auto 1000 Full Up Enable Enable N/A
A link status of Up means that the controller ports are fully operational.

Cisco Catalyst 3750G Specifications

General

Model	Cisco Catalyst 3750G
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
DRAM	128 MB
Flash Memory	16 MB
MAC Address Table Size	12, 000 entries
VLANs	1005
Operating Humidity	10% to 85% non-condensing
Ports	48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP Gigabit Ethernet ports
Jumbo Frames	Up to 9216 bytes
Power Supply	AC
Operating Temperature	0 to 45°C
