Cisco Catalyst 2.4 GHz and 5/6 GHz Dual-Band Polarization-Diverse Directional Patch Antenna (C-ANT9103=)
Figure 5 Exploded View of Antenna and Bracket Hardware Assembly
1
Antenna
7
Mounting arm. One is included in the kit.
2
1
/
4
-inch stainless steel flat washer. Four are included in
the kit.
8
5
/
16
-18 bolt. Two are included in the kit.
3
1
/
4
-inch stainless steel split-lock washer. Four are
included in the kit.
9
M5 x 0.8 bolt. Four are included in the kit.
4
5
/
16
-inch stainless steel split-lock washer. Two are
included in the kit.
10
5
/
16
-18 nut. Two are included in the kit.
5
5
/
16
-inch stainless steel flat washer Two are included in
the kit.
11
Octal DART antenna cable.
6
M8 stainless steel serrated washer. Two are included in
the kit.
12
The articulating mount flange bracket. Two are included in
the kit.
