Cisco Catalyst C-ANT9103 Series User Manual

9
Cisco Catalyst 2.4 GHz and 5/6 GHz Dual-Band Polarization-Diverse Directional Patch Antenna (C-ANT9103=)
Contents of the Antenna and Bracket Kit
Figure 1 Contents of the Antenna Bracket Kit
1
Cap plug. Four are included in the kit.
8
5
/
16
-18 bolt. Two are included in the kit.
2
1
/
4
-inch stainless steel flat washer. Four are included in
the kit.
9
M5 x 0.8 bolt, 14.2 L. Four are included in the kit.
3
1
/
4
-inch stainless steel split-lock washer. Four are
included in the kit.
10
0.3125-18 nut. Two are included in the kit.
4
5
/
16
-inch stainless steel split-lock washer. Two are
included in the kit.
11
#8-18 stainless steel self tap screw. Four are included in
the kit.
5
5
/
16
-inch stainless steel flat washer. Two are included in
the kit.
12
#6-8, 1
1
/
4
-inch anchor. Four are included in the kit.
6
M8 stainless steel serrated washer. Two are included in
the kit.
13
Worm gear clamp hose. Two are included in the kit.
7
Mounting arm. One is included in the kit.
14
Mounting flanges required for installation. Two are
included in the kit.
