Figure 36: C9500-NM-8X Network Module
LEDs2SFP module ports1
Figure 37: C9500-NM-2Q Network Module
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
56
Installing a Network Module
Network Module Overview
