APPENDIX C
Connector and Cable Specifications
• Connector Specifications, on page 113
• Console Cables, on page 114
• Cables and Adapters, on page 115
Connector Specifications
10/100/1000 Ports
All 10/100/1000 ports use standard RJ-45 connectors and Ethernet pinouts.
Figure 86: 10/100/1000 Port Pinouts
Module Connectors
This section describes the different SFP/QSFP/QSFP-DD module connectors used on 10G/25G/40G/100G/400G
ports on the switches.
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
113
