Table 3: Cisco Catalyst 9500 Series Switch Models
Supported portsSwitch model
Cisco Catalyst 9500 Series Switches
Supports standard 12x40G QSFP+ modules.
C9500-12Q
Supports standard 24x40G QSFP+ modules.C9500-24Q
Supports standard 16x10G SFP modules.
The uplink ports support 8x10G SFP/SFP+ modules and 2x40G
QSFP+ modules.
C9500-16X
Supports standard 40x10G SFP modules.
The uplink ports support 8x10G SFP/SFP+ modules and 2x40G
QSFP+ modules.
C9500-40X
Cisco Catalyst 9500 Series High Performance Switches
Supports standard 32x100G or 32x40G QSFP28 modules; all ports
are 100G/40G capable.
C9500-32C
Supports standard 16x100G or 32x40G QSFP28 modules; only the
ports in the top row are 100G capable.
C9500-32QC
Supports standard 24x25G or 24x10G SFP28 modules; all ports are
25G/10G/1G capable.
The uplink ports support 4x100G or 4x40G QSFP+ modules.
C9500-24Y4C
Supports standard 48x25G or 48x10G SFP28 modules; all ports are
25G/10G/1G capable.
The uplink ports support 4x100G or 4x40G QSFP28 modules.
C9500-48Y4C
For information about SFP and QSFP network modules, see Network Modules, on page 18.
Note
Support for Breakout Cables
On Cisco Catalyst 9500 Series High Performance Switches, breakout cables are supported only on the
C9500-32C model. Breakout cables enable a single 40G QSFP+ interface to be split into four 10G SFP+
interfaces and a single 100G QSFP28 interface into four 25G SFP28 interfaces.
For supported SFP and QSFP modules, refer to the Cisco Transceiver Modules Compatibility Information at
https://tmgmatrix.cisco.com/.
Port Mapping for Cisco Catalyst 9500 Series Switches
The odd-numbered ports are on the upper row and the even-numbered ports on the lower row. The following
figures show how the ports and the LEDs are numbered on different switch models. This section also explains
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
11
Product Overview
Port Mapping for Cisco Catalyst 9500 Series Switches
