Table 9: Cisco Catalyst IE3400 Heavy Duty Series Technical Specifications
Environmental Ranges
–40 to 185°F (–40 to 85°C)
Storage temperature
–40 to 167°F (–40 to 75°C)
Operating temperatures exceeding 60C are not covered
by the product safety certifications and approvals.
Caution
• -40C to +70C (Vented Enclosure Operating)
• -40C to +60C (Sealed Enclosure Operating)
• -34C to +75C (200 LFM or more Fan or Blower equipped
Enclosure Operating)
• -40C to +85C (Type Tested to +85C for 16 hours)
Operating temperature
(measured inside enclosure, 1” below
the bottom surface of the switch)
5 to 95% (noncondensing)Operating humidity
IP66 and IP67 Rated for protection against dust and submersion in
water
NEMA type 4x
IP66 and IP67, NEMA type 4x compliant only when all
IP67 cables are mated and torqued appropriately or with
the supplied dust caps attached.
Caution
Ingress Protection/Type Ratings
Up to 15,000 feet (4570 meters)Operating altitude
Up to 40,000 feet (4570 meters)Storage altitude
Table 10: Power Specifications
IE-3400H-24TIE-3400H-16TIE-3400H-8TIE-3400H-24FTIE-3400H16FTIE-3400H-8FTPower Specifications
12 to
48VDC
12 to
48VDC
12 to
48VDC
12 to
48VDC
12 to
48VDC
12 to
48VDC
Marked Input
voltage range
9.6 to
60VDC
9.6 to
60VDC
9.6 to
60VDC
9.6 to
60VDC
9.6 to
60VDC
9.6 to
60VDC
Input voltage range
(Absolute)
5.1A/0.83A4.4A/0.71A3.2A/0.54A4.6A/0.75A4.0A/0.65A3.0A/0.51AInput current @
(9.6V / 60V)
49.0W/49.8W41.6W/42.3W30.4W/32.2W44.2W/45.0W38.4W/39.0W28.8W/30.6WPower consumption
@ (9.6V / 60V)
Cisco Catalyst IE3400 Heavy Duty Series Hardware Installation Guide
32
Technical Specifications
