Table 11: Physical Configurations
IE-3400H-24TIE-3400H-24FTIE-3400H-16TIE-3400H16FTIE-3400H-8TIE-3400H-8FTPhysical
Specifications
9.58 x 13.90 x
3.15 in.
24.33 x 35.31
x 8.00 cm
9.58 x 13.90 x
3.15 in.
24.33 x 35.31
x 8.00 cm
9.58 x 10.90 x
3.15 in.
24.33 x 27.69
x 8.00 cm
9.58 x 10.90 x
3.15 in.
24.33 x 27.69
x 8.00 cm
9.58 x 7.90 x
3.15 in.
24.33 x 20.07
x 8.00 cm
9.58 x 7.90 x
3.15 in.
24.33 x 20.07
x 8.00 cm
Dimensions
(H x W x D)
13.90 lb
6.30 kg
13.90 lb
6.30 kg
11.25 lb
5.10 kg
11.25 lb
5.10 kg
8.45 lb
4.35 kg
8.45 lb
4.35 kg
Weight
(including
mounting
bracket)
Wall mountWall mountWall mountWall mountWall mountWall mountMounting
Connectors and Cabling
The connectors and cabling for the Cisco Catalyst IE3400 Heavy Duty Series switches are below.
Table 12: Cisco Catalyst IE3400 Heavy Duty Series Cables and Connectors
• Copper 100 Base-T M12 D coded 4 pole (pin) cable: M12 Male and/or
M12/RJ-45 connector
• Copper GE M12 X coded 8 pole (pin) shielded cable: M12 Male and/or
M12/RJ-45 connector
Data Ports
• Copper M12 A-Coded 5 Pin connectorAlarm Port
• Mini Style 4-pin connector for power inputPower Input
• Console Cable 6ft with M12 and DB9F for IE3400H SwitchConsole Cable:
CAB-CONSOLE-M12=
Torque Specifications
The torque specifications for the Cisco Catalyst IE3400 Heavy Duty Series switches are below.
Table 13: Cisco Catalyst IE3400 Heavy Duty Series Torque Specs
• 4.43 to 7.08 in-lbs (0.5 to 0.8
Nm)
Alarm, Console, Ethernet ports (M12 Connectors)
• 3.5 in-lbs (0.4 Nm)M12 Connector Dust Cap (Alarm, Console, Ethernet ports)
• 10 in-lbs (1.13 Nm)Power Supply Connector (Mini-Change)
Cisco Catalyst IE3400 Heavy Duty Series Hardware Installation Guide
33
Technical Specifications
Connectors and Cabling
