TypeDescriptionConnector
BNCThe SDI outputs provide serial digital video with embedded
audio output for applications. The following lists the
supported SDI standards:
•
HD-SDI (SMPTE-292M)
•
SD-SDI (SMPTE ST 259)
•
3G-SDI (SMPTE ST 424)
This is only available on the single-stream units
with the SDI option installed (D9800-3G-SDI).
Note
SDI 1 and SDI 2
BNCThe composite video output provides one SD composite
video output for monitoring applications and downstream
equipment.
This is available on the single-stream units
only.
Note
CVBS (Composite Video
Output)
HDMI Type A
receptacle (female)
The HDMI output is for monitoring purposes only.
This is available on the single-stream units
only.
Note
HDMI
BNCAsynchronous Serial Interface (ASI) input and/or output
ports. The single-stream units have one ASI input port and
one ASI output port. The multi-stream units have two ASI
input and/or output ports.
ASI IN and ASI OUT
(D9800-SS)
ASI I/O 1 and ASI I/O 2
(D9800-MS)
15-pin sub-D
female
Program relay provides programmed responses for alarms,
cue trigger states for ad-insertion equipment, or a cue tone
output for connection to ad-insertion equipment.
This is available on the single-stream units
only.
Note
Cue Tone/Cue Trigger
Relay Output
—
This is not supported in the current release.USB
RJ-45Supports the following network protocols: SSH, HTTPS,
SNMP, Syslog, and NTP.
Management
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
4
Installing the D9800 Network Transport Receiver
Rear Connector Panels
