To avoid electrical shock, connect the three-prong plug on this product to an earth-grounded three-pin
socket outlet only.
Caution
Step 1
Connect the power cord (supplied with the unit) between the rear panel power receptacle and a 100 to 120/200 to 240
V AC, 50/60 Hz power outlet.
Step 2
Ensure that the power cable is connected to protective ground. See Grounding or Earthing, on page 2.
The Application Starting message appears on the front panel. The boot process, for a unit with a typical configuration,
may take up to two to three minutes to initialize. When ready, the front panel displays the startup screen.
Maintenance of EMC Compliance
For EMC protection, shielded cables must be used. Double-shielded (braid/foil or braid/braid) cables should
be used for all ASI I/O, CVBS, SDI, and RF inputs. Single-shield cables are acceptable for all other inputs
and outputs (AES audio, Ethernet). For Audio terminal block and Cue I/O, no shielding is required.
Connecting to the Satellite Input
Step 1
Set the 22 kHz signal and the output voltage, as required.
Step 2
Connect the ASI OUT port to an ASI device for digital tier applications.
Connecting the Input/Output Signals
This section describes how to connect the RF inputs, ASI input, ASI output, video outputs, and audio outputs.
Connecting the RF Inputs
Connect up to four LNB RF cables to the RF connectors labeled RF1 through RF4 on the rear of the unit.
Use 75-ohm (braid/foil or braid/braid), low insertion loss coaxial cable.
Each input accepts an LNB signal input. RF2 to RF4 require an external LNB power source.
Connecting the ASI Input
If desired, connect to the ASI IN port to an asynchronous serial interface for uplink monitoring.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
6
