Getting Started and Product Document of Compliance for the Cisco IR1101 Industrial Integrated Services Router
Figure 7 Pluggable Module Insert
9. Attach your antennas to the ports on the pluggable module. There are different instructions for each antenna type,
be sure to consult the antenna documentation for proper orientation and torque to install them.
10. If no antennas are being installed on a port, make sure the caps are installed on the connector.
