Cisco IR1101 User Manual

Technology SupportedDescriptionModem UsedSKU ID
Multimode LTE 3.0 for carriers that operate
FDD LTE 700-MHz (band 28), 850-MHz
(band 5 CLR), 850-MHz (bands 18 and 19
Low), 900-MHz (band 8), 1500-MHz (band
21), 1800-MHz (band 3), 2100-MHz (band 1),
or 2600-MHz (band 7) networks; the
multimode Cisco LTE Advanced 3.0 NIMs
are backward-compatible with UMTS and
DC-HSPA+: 800 MHz (band 19 Japan), 850
MHz (band 5), 850 MHz (band 6 Japan), 900
MHz (band 8), 1800 MHz (band 9), 2100 MHz
(band 1), and TD-SCDMA 39.
Multimode LTE Advanced 3.0 for carriers that
operate TDD LTE 1900 MHz (band 39), 2300
MHz (band 40), 2500 MHz (band 41), or 2600
MHz (band 38).
Multimode LTE Advanced 3.0 for carrier
aggregation band combinations:
1+(8,18,19,21); 3+(5,7,19,28); 7+(5,7,28);
19+21, 38+38, 39+39, 40+40, and 41+41.
APACEM7430P-LTEA-LA
Multimode LTE Advanced 3.0 for carriers that
operate FDD LTE 700-MHz (band 12),
700-MHz (band 29), 800-MHz (band 20),
850-MHz (band 5 CLR), 850-MHz (bands 26
Low), 900-MHz (band 8), 1800-MHz (band
3), 1900-MHz (band 2), 1900-MHz (PCS band
25), 1700-MHz and 2100-MHz (band 4 AWS),
2100-MHz (band 1), 2300-MHz (band 30), or
2600-MHz (band 7) networks. The multimode
Cisco LTE Advanced 3.0 NIMs are backward
compatible with Universal Mobile
Telecommunications Service (UMTS) and
Dual-Carrier High-Speed Packet Access Plus
(DC-HSPA+): 850-MHz (band 5), 900-MHz
(band 8), 1800-MHz (band 3), 1900-MHz
(band 2), 1700-MHz and 2100-MHz (band 4
AWS), and 2100-MHz (band 1).
Multimode LTE Advanced 3.0 for carriers that
operate TDD LTE 2500-MHz (band 41).
Multimode LTE Advanced 3.0 for carrier
aggregation band combinations: 1+8;
2+(2,5,12,13,29); 3+(7,20); 4+(4,5,12,13,29);
7+(7,20); 12+30, 5+30, and 41+41.
USA, Canada, Europe,
Latin America
EM7455P-LTEA-EA
Product Overview
16
Product Overview
Modem Support

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
