Prerequisite for Installing the DSL SFP
The DSL SFP will only function on IOS-XE release 17.4.1 and above.
Due to a change in the IR1101 Faceplate, older routers are not able to use the DSL SFP. There is no viewable
version on the IR1101 Faceplate, but you can determine if your router is new enough to use the DSL SFP
through the show inventory command:
IR1101#show inventory
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
INFO: Please use "show license UDI" to get serial number for licensing.
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
NAME: "Chassis", DESCR: "IR1101 Base Chassis"
PID: IR1101-K9 , VID: V05 , SN: FCW23500H5X
NAME: "Module 0 - Mother Board", DESCR: "Cisco IR1101 motherboard"
PID: IR1101-K9 , VID: V05 , SN: FOC23473SRK
NAME: "module subslot 0/0", DESCR: "IR1101-ES-5"
PID: IR1101-ES-5 , VID: V01 , SN:
NAME: "subslot 0/0 transceiver 0", DESCR: "GE T"
PID: SFP-VADSL2+-I , VID: V01 , SN: MET2023000A
The IR1101 K9 VID version must be equal to, or greater than V05 as shown above.
DSL SFP Overview
The DSL SFP interface is an 8 pin modular jack. The following table shows the pin-out assignments:
Pin AssignmentPin Number
Not Used1
Not Used2
Not Used3
Analog Input4
Analog Input5
Not Used6
Not Used7
Not Used8
The modular jack pin-outs are shown in the following graphics:
