Cisco IR1101 User Manual

• LED Indicator: provision-able, On: Active, Off: Non-active.
• Electrical isolation: 2000 VDC.
• 4kV Surge protected (IEC 61000-4-5).
IR-1100-SPMI Expansion Module LEDs
There are 6 LEDs in the Expansion Module. Four LEDs show the status of digital input and output. One LED
shows the SFP port status and one LED shows the mSATA status. The LED behavior is shown in the following
table.
Table 6: Expansion Module LEDs
DefinitionLED
Off - InactiveSolid Yellow- ActiveDigital I/O as Input
Off - InactiveSolid Yellow- ActiveDigital I/O as Output
Off - No LinkSolid Yellow - Port link with no activityFlashing Yellow - Port link healthy with activitySFP
Off - Not powered on or no activityFlashing Green - mSATA being accessedmSATA
Cisco IR-1100-SP Expansion Module
The IR-1100-SP Expansion Module is the same as the IR-1100-SPMI module, without the Digital I/O and
mSATA components.
The following lists the hardware platform features for the Cisco IR-1100-SP:
• 1 GE SFP (see the supported list of SFP’s here: SFP Module, page 26 )
• 1 Pluggable slot
Cisco Pluggable Module
The Pluggable Module provides the flexibility of adding different interfaces to the IR1101 platform, for
example, a cellular module.
Pluggable LTE Module
Highlights of the LTE Pluggable Module are:
• All Cellular interfaces are supported through a Pluggable Module
• Micro-Sim, 3FF size. Cisco recommends Industrial Temp micro SIMs that are rated from -40C to +105C.
The following two figures show an example of a Pluggable Module. In this case, the LTE Pluggable Module.
Product Overview
9
Product Overview
IR-1100-SPMI Expansion Module LEDs

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
