Figure 8: LTE Pluggable Module (front)
LTE-Main SMA1
GPS SMA2
Micro USB Debug Port3
LTE-Div SMA4
Figure 9: LTE Pluggable Module (with antennas)
LTE Category 18 Pluggable Module
This module has a new smaller form factor SMA Diversity Antenna for usability and Micro-USB port access.
Product Overview
10
Product Overview
LTE Category 18 Pluggable Module
