Voice Gateway with Router
10
Chapter 4: Getting Started
Connecting the Voice Gateway
4. Connect one end of an Ethernet network cable (included) to the ETHERNET port of the Voice Gateway.
Connect the other end to the Ethernet port of your PC.
5. Connect one end of a different Ethernet network cable to the INTERNET port of the Voice Gateway. Connect
the other end to your cable/DSL modem.
6. Power on the broadband modem.
7. Connect the included power adapter to the Voice Gateway’s power port, and then plug the power adapter
into an electrical outlet. The power LED on the front panel will light up as soon as the Voice Gateway
powers on.
8. Power on your PC.
Proceed to the next section.
Figure 4-3: Connect a PC
Figure 4-4: Connect to the Modem
NOTE: Make sure your PC’s Ethernet adapter is set to obtain an IP address automatically. For
more information, refer to Windows Help.
Figure 4-5: Connect Power
