Cisco MDS 9000 Series Hardware Installation Guide

StateStatusColorFunctionIndicator
All diagnostics have passed, Cisco NX-OS
is running and the system is operational.
Solid On
GreenSystem
Status
STATUS:
Status LED
(front panel of
the chassis)
Any of the following conditions exists:
• The system is running bootup
diagnostics.
• The system is booting.
• A minor temperature threshold is
exceeded.
Solid OnOrange
Mismatched airflow direction in one of the
following modules:
• Fan modules—The switch will shut
down in 10-15 seconds.
• PSUs—The switch will shut down
after 10 minutes.
• Fan modules and PSUs—The switch
will shut down after 10 minutes.
BlinkingRed
One of the following conditions exists:
• A diagnostic test failed or another fault
occurred during bootup.
• A major temperature threshold is
exceeded.
Solid On
All chassis fan modules are operational.Solid onGreen
Fan HealthFAN: Fan
status
(front panel of
the chassis)
A chassis fan module has failed.Solid onRed
No input to the PSU.Off
GreenVoltage
Status
PSU Voltage
Status LED
(faceplate of
each PSU)
PSU output is OK.Solid on
PSU output is not OK, but input is OK.Blinking
Cisco MDS 9148V-K9 Switch Hardware Installation Guide
9
Overview of Cisco MDS 9148V-K9 Switch
LEDs

Cisco MDS 9000 Series Specifications

General

Category	Switch
Operating System	Cisco NX-OS
Ports	Varies by model
Protocols	Fibre Channel (FC), Fibre Channel over IP (FCIP), iSCSI
Redundancy	Redundant supervisors, power supplies, and fans
Management	Cisco Data Center Network Manager (DCNM), CLI, SNMP
Virtualization Support	VSANs (Virtual SANs)
Security Features	Fibre Channel Security Protocol (FC-SP)
Hot Swappable Components	power supplies, fans
Power Supply Options	AC and DC options available
