2-10
Cisco ME 3800X and ME 3600X Switch Hardware Installation Guide
OL-22168-01
Chapter 2 Switch Installation
Installing the Switch
Attaching Angle Brackets for 23-Inch Racks
Figure 2-3 shows how to attach the angle brackets for 23-inch racks on the switch.
Note Use the holes marked R to install the bracket on the right side; use the holes marked L to install the
bracket on the left side.
Figure 2-5 Attaching Angle Brackets for 23-Inch Racks
1 Phillips flat-head screws 2 Mid-mounting position
1
2
279252
