Verifying Wavelength and Channel Mapping for Optics
Controllers
Some of the troubleshooting scenarios where you need to verify the wavelength and channel mapping of the
optics controllers are:
• Verify the connection between the NCS 1002 and a line system.
• Troubleshoot problems with the traffic.
• Clear an LOS.
show controllers optics R/S/I/P dwdm-carrrier-map
Displays the wavelength and channel mapping for optics controllers.
RP/0/RP0/CPU0:ios# show controllers optics 0/0/0/11 dwdm-carrrier-map
Thu Aug 27 15:59:00.385 UTC
DWDM Carrier Band:: C-Band
MSA ITU channel range supported: 1~97
DWDM Carrier Map table
----------------------------------------------------
ITU Ch G.694.1 Frequency Wavelength
Num Ch Num (THz) (nm)
----------------------------------------------------
1 60 196.10 1528.773
----------------------------------------------------
2 59 196.05 1529.163
----------------------------------------------------
3 58 196.00 1529.553
----------------------------------------------------
4 57 195.95 1529.944
----------------------------------------------------
5 56 195.90 1530.334
----------------------------------------------------
6 55 195.85 1530.725
----------------------------------------------------
7 54 195.80 1531.116
----------------------------------------------------
8 53 195.75 1531.507
----------------------------------------------------
9 52 195.70 1531.898
----------------------------------------------------
10 51 195.65 1532.290
----------------------------------------------------
11 50 195.60 1532.681
----------------------------------------------------
Troubleshooting Guide for Cisco NCS 1002, IOS XR Release 6.3.x
28
General Troubleshooting
Verifying Wavelength and Channel Mapping for Optics Controllers
