StatusColorLED
The module is operational and has no active major or critical alarms.GreenSTATUS or
STAT
Host kernel booted and is ready to start SysAdmin VM.Amber
Power-up failure which prevents the CPU from booting.Red
The module is booting up.Flashing Amber
(Slow)
The module is booting up, shutting down, or the SysAdmin VM is being
reloaded.
Flashing Amber
(Fast)
RP0 has active major or critical alarms.Flashing Red
The module is powered-off.Off
Critical alarm - system-scope (including RP0).RedALARM or
ALRM
Critical alarm. The source can be any of the following:
•
Less than 2 PSUs
•
Power cord not plugged in
•
PSU not inserted properly
•
Input power not good
Flashing green
(Applies to NCS
5502 only)
Critical alarm - Relating to voltage rail failures.Flashing Red
Major alarm - system-scope (including RP0).Amber
Minor alarm - system-scope (including RP0).Flashing Amber
No alarm.Off
Time core is synchronized to an external source including IEEE1588.GreenSYNC
(Does not apply
to NCS 5501 or
5502)
System is in Synchronous Ethernet Mode.Flashing Green
Free run/Holdover - Time core is in free run or holdover mode.Amber
Time core clock synchronization is disabled.Off
Secure Boot validation failure state. This case is only applicable
immediately after power on.
Flashing RedSTATUS +
ALARM (Both
LEDs)
Hardware Installation Guide for Cisco NCS 5500 Series Fixed-Port Routers
70
LEDs
Chassis LEDs
