TransceiversPorts/AdaptersLine Card
Second-generation
Coherent Transceiver
Pluggable (CTP2) optics
modules (in CFP2
form-factor).
6 x 100GE–Supports 100 Gbps (DWDM QPSK),
150 Gbps (DWDM 8 QAM), or 200 Gbps (DWDM
16 QAM) WDM signals with full line-rate MACsec
capability.
NC55-6X200-DWDM-S
Adds DWDM capabilities to the NCS 5500 series
modular chassis.
Along with the ONS-CFP2-WDM long-haul optics,
this line card eliminates the need to connect
short-range grey optics to a dedicated optical
platform between NCS 5500 series modular chassis,
reducing operating expenses and capital costs.
SFP/SFP+
QSFP+
• 12 x 1GE/10GE
• 2 x 40GE
• 2 modular port adapters (MPAs). See the
Modular Port Adapters section for port details.
NC55-MOD-A-S
NC55-MOD-A-SE-S— has external TCAM for
supporting expanded Forwarding Information Base
(FIB), network access control lists (ACLs), and QoS
for scale-enhanced configuration needs.
QSFP+
QSFP28
QSFP-DD
• 24 ports x 400GE
• 40GE (4x10GE) and 100GE (4x25GE) with
QSFP28 optics
• 400GE (4x100GE) and 200GE (2x100GE) with
QSFPDD optics
NC57-24DD—Supported in the NCS 5508 and NCS
5516 chassis with second generation fabric cards
(NC55-5508-FC2/NC55-5516-FC2) and fan trays
(NC55-5508-FAN2/NC55-5516-FAN2). Requires
Cisco IOS XR 7.0.2 or later.
QSFP+
QSFP28
QSFP-DD
• 18 x 400GE (12 ports unused)
or
30 x 200GE – 200GE, 100GE
• 40GE (4x10GE) and 100GE (4x25GE) with
QSFP28 optics
• 400GE (4x100GE) and 200GE (2x100GE) with
QSFPDD optics
NC57-18DD-SE—Supported in the NCS 5508 and
NCS 5516 chassis with second generation fabric
cards (NC55-5508-FC2/NC55-5516-FC2) and fan
trays (NC55-5508-FAN2/NC55-5516-FAN2).
Requires Cisco IOS XR 7.0.2 or later.
For NC57-18DD-SE line card, there are eighteen 400GE ports which are the even numbered ports between
Port 0 and Port 29, Port 19, Port 21 and Port 23. The 400GE ports are marked on the front panel with blue
indicator (see Figure 1: NC57-18DD-SE Line Card, on page 6).
In 400GE configuration, the odd numbered ports (except Port 19, Port 21, and Port 23) marked in orange at
the bottom row (see Figure 1: NC57-18DD-SE Line Card, on page 6) are not used.
The NC57-18DD-SE supports 200GE optics or 100GE optics in all 30 ports.
Hardware Installation Guide for Cisco NCS 5500 Series Modular Routers
5
NCS 5500 Series Modular Router Overview
Line Card Overview
