StatusFAIL or FAIL/ID LEDOK LED
Power supply is connected to input power source but not outputting
power to the router. The power supply might not be properly installed
in the chassis.
OffFlashing green
Either all of the installed power supplies are not receiving power or
an uninstalled power supply is not receiving power.
OffOff
Power supply is operating but a warning condition has
occurred—possibly one of the following conditions:
• High temperature
• High power
• Slow power supply fan
• Low voltage
• Power supply is installed in the chassis but was disconnected
from the power source
Flashing amberOff
Power supply is installed without a connection to a power source.Flashing amber (10
seconds) then amber
Off
Power supply failure—possibly one of the following conditions:
• Over voltage
• Over current
• Over temperature
• Power supply fan failure
AmberOff
Table 15: HVAC/HVDC Power Supply LED Descriptions
StatusFAIL/ID LEDOUT LEDIN LED
Both inputs are connected to power source.
Power supply is on and outputting power
to the router.
OffGreenGreen
Power supply is connected to input power
source but not outputting power to the
router. The power supply might not be
properly installed in the chassis.
OffGreenFlashing green
Hardware Installation Guide for Cisco NCS 5500 Series Modular Routers
139
LEDs
LEDs
