Maximum PowerTypical PowerWeight per UnitComponent
300W at 55°C243W at 27°C22.8 lbs (10.34 kgs)Cisco NCS 5501 Chassis (NCS-5501)
330W at 55°C280W at 25°C23.5 lbs (10.66 kgs)Cisco NCS 5501 SE Chassis (NCS-5501-SE)
Power Supply (2 maximum)
NA2.8 lb
•
NCS 5500 1100W AC Power Supply, Forward Airflow
(Port side intake): NCS-1100W-ACFW
•
NCS 5500 1100W AC Power Supply, Reverse Airflow (Port
side exhaust): NCS-1100W-ACRV
•
NCS 5500 950Watts DC Power Supply, Forward Airflow
(Port side intake) NCS-950W-DCFW
•
NCS 5500 1100W DC Power Supply, Reverse Airflow (Port
side exhaust): NCS-1100W-DCRV
See the following table for details10 OzFan Tray (2 maximum)
•
NCS-1RU-FAN-FW
•
NCS-1RU-FAN-RV
Table 11: NCS 5501 and NCS 5501 SE Fan Tray Power Consumption
Total Fan Tray Power ConsumptionQuantity of Fan traysPower Consumption of Each Fan
Tray
Ambient Temperature
22W211W25°C
82W241W55°C
NCS 55A1 Fixed Chassis Weight, Quantity and Power Consumption
The NCS 55A1 fixed chassis offers two hot-swappable power supplies providing 1+1 redundancy. For 1+1
redundancy mode, there must be two subsystems each, providing enough power supply to maintain the system.
Table 12: NCS 55A1-24H, NCS 55A1-36H-S Weight, Quantity and Power Consumption
Maximum PowerTypical PowerWeight per UnitComponent
Chassis
800W at 55°C600W at 27°C24 lbs (10.89 kgs)Cisco NCS 55A1-24 Chassis (NCS-55A1-24H)
1450W at 55°C1100W at 27°C33 lbs (14.97 kgs)Cisco NCS 55A1-36H-S Chassis (NCS-55A1-36H-S)
Hardware Installation Guide for Cisco NCS 5500 Series Fixed-Port Routers
65
System Specifications
Weight, Quantity and Power Consumption
