REVIEW DRAFT—CISCO CONFIDENTIAL
A-3
Getting Started with Cisco Network Assistant
OL-6194-07
Appendix A Configuring a Catalyst 4500 Series Switch for Network Assistant Management
Additional Configuration Required to Manage a Community
Note If you have enabled clustering, disable clustering before configuring a community.
If you plan to use a community, define an IP address on each switch:
Additional Configuration Required to Manage a Cluster
If you plan to use clustering, enter the cluster run global configuration command on each device, and
enter the ip address interface configuration command on the cluster commander:
Command Purpose
Step 1
Switch# configuration terminal
Enter global configuration mode.
Step 2
Switch(config)# interface {vlan
vlan_ID
|
{fastethernet | gigabitethernet}
slot/interface
| Port-channel
number
}
Select an interface.
Step 3
Switch(config-if)# ip address
ip_address
address_mask
(Optional) Assign an IP address to the Catalyst 4500 series.
Note This step is mandatory if the switch is part of
community or is a cluster command switch. This step
is optional if the switch is a cluster member
candidate.
Step 4
Switch(config-if)# end
Return to privileged EXEC mode.
Step 5
Switch# show running-config
Verify the configuration.
Command Purpose
Step 1
Switch# configuration terminal
Enter global configuration mode.
Step 2
Switch(config)# cluster run
Enable clustering.
Note Enable clustering on all switches that are part of the
potential cluster.
Step 3
Switch(config)# cluster enable
Name the cluster.
Step 4
Switch(config)# interface {vlan
vlan_ID
|
{fastethernet | gigabitethernet}
slot/interface
| Port-channel
number
}
Select an interface.
Step 5
Switch(config-if)# ip address
ip_address
address_mask
(Optional) Assign an IP address to the Catalyst 4500 series
switch cluster master.
Note This step is mandatory if the switch is part of a
community or is a cluster command switch. This step
is optional if the switch is a cluster member
candidate.
