Figure 1: Fan-Side View of the Cisco Nexus 3016 Chassis
Status LED5AC or DC power supply
(1 or 2)
1
USB port (1)6Fan tray (1)2
Console port (1)7Management ports (2)3
ID LED4
The following figure shows the port-side chassis features that you use when installing the chassis or replacing
its modules.
Cisco Nexus 3000 Series Hardware Installation Guide
2
Overview
Overview of the Cisco Nexus 3016 Switch
