1-34
Cisco Nexus 5000 Series Hardware Installation Guide
Chapter 1 Overview
Cisco Nexus 5000 Platform Switches
N5K-M1008 Generic Expansion Module
The N5K-M1008 GEM supports 8 4-, 2-, or 1-Gbps Fiber Channel, SFP-based uplink connections.
Figure 1-33 shows the features used when installing this expansion module.
Figure 1-33 N5K-M1008 GEM
Figure 1-34 Front View of the N5K-M1008 GEM
N5K-M1060 Generic Expansion Module
The N5K-M1060 expansion module provides 6 EA 8-, 4-, 2-, or 1-Gbps line rate Fiber Channel, SFP+
based uplink connections. Figure 1-35 and Figure 1-36 show the N5K-M1060 GEM.
189953
189954
2
1
2
3
4
5
6
7
8
1
1 Eight 4-, 2-, or 1-Gbps Fibre Channel ports 2 LED
