Cisco Nexus 5596UP - Power Supply

1-8
Cisco Nexus 5000 Series Hardware Installation Guide
Chapter 1 Overview
Cisco Nexus 5500 Platform Switches
Power Supply
The Cisco Nexus 5596UP uses a front-end power supply. The chassis has slots for two power supplies.
The Cisco Nexus 5596UP switch is fully functional with one power supply, but you can include a second
power supply for power redundancy.
Table 1-1 lists the power supplies that you can order with the Cisco Nexus 5596UP and 5596T switches.
Note Front to Back (FAF) Airflow and DC Power Supply is now supported for the Cisco Nexus 5596T. For
details see the Cisco Nexus 5500 Datasheet.
Figure 1-8 shows an AC power supply. For more information on the LEDs, see Table D-1 on page D-2.
Table 1-1 Power Supplies for the Cisco Nexus 5596UP and 5596T switches
Part Number Power Supply
N55-PAC-1100W Cisco Nexus 5596UP PSU Port-Side Exhaust Airflow module, A/C,
100-240V, 1100W
N55-PAC-1100W(=) Cisco Nexus 5596UP PSU Port-Side Exhaust Airflow module spare, A/C,
100-240V, 1100W
N55-PAC-1100W-B Cisco Nexus 5596UP/5596T PSU Port-Side Intake Airflow module, A/C,
100-240V, 1100W
N55-PAC-1100W-B(=) Cisco Nexus 5596UP/5596T PSU Port-Side Intake Airflow module spare,
A/C, 100-240V, 1100W
N55-PDC-1100W Cisco Nexus 5596UP/5596T PSU DC Port-Side Exhaust module, 1100 W
N55-PDC-1100W(=) Cisco Nexus 5596UP/5596T PSU DC Port-Side Exhaust module spare,
1100 W
NXA-PHV-1100W Cisco Nexus 5500/6000 Platinum HV-AC-DC PS, Port side Exhaust airflow,
1100W
NXA-PHV-1100W(=) Cisco Nexus 5500/6000 Platinum HV-AC-DC PS, Port side Exhaust airflow,
1100W, spare
NXA-PHV-1100W-B Cisco Nexus 5500/6000 Platinum HV-AC-DC PS, Port side Intake airflow,
1100W
NXA-PHV-1100W-B(=) Cisco Nexus 5500/6000 Platinum HV-AC-DC PS, Port side Intake airflow,
1100W, spare
