Chapter 1 Overview
Cisco Nexus 7000 Series
1 Door for the cable
management area
5 Handles used to reposition the chassis (do not lift the chassis
with these handles—use a mechanical lift)
2 System status LEDs 6 I/O modules (1 to 8) in slots 1 to 4 and 7 to 10—these modules
are a combination of the following:
• 48-port 10/100/1000 I/O modules (N7K-M148GT-11)
• 48-port 10/100/1000 I/O modules with XL option
(N7K-M148GT-11L)
• 48-port 1-Gigabit Ethernet I/O modules
(N7K-M148GS-11)
• 48-port 1-Gigabit Ethernet I/O modules with XL option
(N7K-M148GS-11L)
• 48-port 1-/10-Gigabit Ethernet I/O modules with XL
(N7K-F248XP-25)
• 32-port 10-Gigabit Ethernet I/O modules
(N7K-M132XP-12)
• 32-port 10-Gigabit Ethernet I/O modules with XL option
(N7K-M132XP-12L)
• 32-port 1- and 10-Gigabit Ethernet I/O modules
(N7K-F132XP-15)
• 8-port 10-Gigabit Ethernet I/O modules with XL option
(N7K-M108X2-12L)
3 Cable management area
(upper routing portion can
be removed if necessary)
7 Supervisor modules (1 or 2) in slots 5 and 6 (N7K-SUP1)
4 Rack mount bracket (2) (one
on each side)
8 Air intake (shown without the optional air filter)
