Cisco Nexus 93600CD-GX Series - Switch Installation with NXK Kit

Depth of the front clearance area (equal to the
depth of the chassis).
7Chassis width
17.3 in (43.9 cm)
3
Width of the front clearance area (equal to the
width of the chassis with two rack-mount
brackets that are attached to it).
19.0 in (43.3 cm)
4
Both the front and rear of the chassis must be open to both aisles for airflow.
Note
Cisco Nexus 93600CD-GX ACI-Mode Switch Hardware Installation Guide
11
Preparing the Site
Clearance Requirements
