Switch and Module Weights and Quantities
QuantityWeight per UnitComponent
128 lb (12.7 kg)Cisco Nexus 93600CD-GX Chassis (N9K-C93600CD-GX)
6 (5 for operations
and 1 for
redundancy)
—
0.26 lb (0.12 kg)
Fan Module
– Port-side exhaust (blue) (NXA-FAN-35CFM-PE)
– Port-side intake (burgundy) (NXA-FAN-35CFM-PI)
2 (1 for operations
and 1 for
redundancy)
—
2.64 lb (1.2 kg)
Power Supply Module
– 1100-W AC port-side exhaust (blue) (NXA-PAC-1100W-PE2)
– 1100-W AC port-side intake (burgundy) (NXA-PAC-1100W-PI2)
– 1100-W DC port-side exhaust (blue) (NXA-PDC-1100W-PE)
– 1100-W DC port-side intake (burgundy) (NXA-PDC-1100W-PI)
– 1100-W HVAC/HVDC port-side exhaust (blue) (NXA-PHV-1100-PE)
– 1100-W HVAC/HVDC port-side intake (burgundy) (NXA-PHV-1100-PI)
Transceiver and Cable Specifications
To determine which transceivers, adapters, and cables are supported by this switch, see https://www.cisco.com/
c/en/us/support/interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
To see the transceiver specifications and installation information, see https://www.cisco.com/c/en/us/support/
interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
Switch Power Input Requirements
The following table lists the typical amount of power that the switch consumes. It also lists the maximum
amount of power that you must provision for the switch and power supply for peak conditions.
Some power supplies have capabilities that are greater than the maximum power requirements for a switch.
To determine the power consumption characteristics for the switch, use the typical and maximum requirements
that are listed in the following table.
Note
Heat Dissipation
Requirement
Maximum Power
Consumption (AC or
DC)
Typical Power Consumption (AC or DC)Switch
3,753.356 BTUs
per hour
1100 W590 WCisco Nexus 93600CD-GX
Cisco Nexus 93600CD-GX ACI-Mode Switch Hardware Installation Guide
52
System Specifications
Switch and Module Weights and Quantities
