1-9
Cisco ONS 15454 Procedure Guide, Release 8.5.1
78-18537-01
Chapter 1 Install the Shelf and Backplane Cable
NTP- A6 Install the Power and Ground
Note To attach cables to the EIAs, see the “NTP-A9 Install the Electrical Card Cables on the
Backplane” procedure on page 1-22.
Step 7 Continue with the “NTP-A6 Install the Power and Ground” procedure on page 1-9.
Stop. You have completed this procedure.
NTP-A6 Install the Power and Ground
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning
This equipment is intended to be grounded. Ensure that the host is connected to earth ground during
normal use.
Statement 39
Warning
Use copper conductors only.
Statement 1025
Purpose This procedure installs power feeds and grounds the ONS 15454.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Screws
Power cable (from fuse and alarm panel to assembly), #10 AWG, copper
conductors, 194 degrees F (90 degrees C)
Ground cable (from equipment frame to office ground), #6 AWG stranded
Listed pressure terminal connectors, typically dual lug type; connectors
must be suitable for #6 AWG copper conductors with stud size and spacing
per equipment rack specifications; connection to office ground typically
through H-TAP compression connector, according to site practice
Wire cutters
Wire strippers
Crimp tool
Fuse panel
Prerequisite Procedures NTP-A4 Remove the Backplane Covers, page 1-7
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
